Manufacturer：SZBONAD brand of power sensor with 266nm-10.6um Absorption,25mm Aperture which is high linearity and absorption. more details please contact us: 13380391156
Product Description：
China supplier 10W Power Sensor
Features of power sensor:
1. High linearity; 2. High absorption; 3. 25mm aperture 4. Convection cooling.
Model
BND-10ZC-D25
Absorption
90%
WavelengthRange
266nm-10.6um
PowerRange
0.1-10W
Scale
Auto
Aperture
25mm
PowerResolution
0.001W
ResponseTime(0-95%)(a)
<5s
CalibrationUncertainty
<3%
Non-linearity
<±1%
Accuracy
±3%
DamageThreshold(b)
10kW/cm2@10W
Cooling
Convection
Dimension
52×52×33.5mm
CableLength
1.5m
ConnectorType
DB15
Notes : (a).Time from zero to 95%of stable value; (b).When measuring a very small beam diameter or power higher than 10W for a long time,there is a risk of damage when the temperature exceeds 200℃.
