No.
|
Product name
|
standard
|
Quantity
|
|
1
|
Figure 1 — Test pin
|
BS1363-1-Fig1
|
1
|
|
2
|
2a)Apparatus for mechanical strength test on resilient covers 2b)Hardwood block for Figure 2a)
|
BS1363-1-Fig2
|
2
|
|
3
|
Figure 4a) — Dimensions and disposition of pins
Figure 4b) — Concave shrinkage allowance for ISOD
|
BS1363-1-Fig4
|
2
|
|
4
|
Figure 5 — Gauge for plug pins
|
BS1363-1-Fig5
|
1
|
|
5
|
Figure 6 — Apparatus for testing plug cover fixing screw
|
BS1363-1-Fig6
|
1
|
|
6
|
Figure 7—Mounting plate
|
BS1363-1-Fig7
|
1
|
|
7
|
Figure 8—Plug pin deflection test apparatus for resilient plugs
|
BS1363-1-Fig8
|
1
|
|
8
|
Figure 9— Apparatus for abrasion test on insulating sleeves of plug pins
|
BS1363-1-Fig9
|
1
|
|
9
|
Figure 10 — Apparatus for pressure test at high temperature
|
BS1363-1-Fig10
|
|
|
10
|
Figure 11 — Go gauge for socket-outlet
|
BS1363-1-Fig11max/min
|
2
|
|
11
|
Figure 17a) — Test apparatus for temperature rise test Figure 17b) — Dummy front plate for temperature rise test
|
BS1363-1-Fig17a.b
|
2
|
|
12
|
Figure 18 — Apparatus for flexing test
|
BS1363-1-Fig18
|
1
|
|
13
|
Figure 19 — Solid link for test on fuse clips
|
BS1363-1-Fig19
|
1
|
|
14
|
Figure 20 — Tumbling barre
|
BS1363-1-Fig20
|
1
|
|
15
|
Figure 23 — Apparatus for pressure test
|
BS1363-1-Fig23
|
1
|
|
16
|
Figure 24 — Apparatus for ball pressure test
|
BS1363-1-Fig24
|
1
|
|
17
|
Figure 28 — Calibrated link
|
BS1363-1-Fig28
|
1
|
|
18
|
Figure 29 — Calibration jig for calibrated link
|
BS1363-1-Fig29
|
1
|
|
19
|
Figure 32 — Apparatus for tests on plug pin
|
BS1363-1-Fig32
|
1
|
|
20
|
Figure 33 — Apparatus for torsion test on pins
|
BS1363-1-Fig33
|
1
|
